Free workshop printables
Measurement sheets and true-size gauges
True-size gauges and record sheets for the measurements a seller will ask you for.
This is the section a chatbot cannot replace. It can tell you what a belt marking means; it cannot lay a true-size 18.5mm bar next to the belt in your hand. Every sheet here that shows something at actual size also carries a printed millimetre rule, so a mis-scaled printout is caught before it produces a wrong number that looks right.
Mystery part measurement sheetYou are holding a part. Nobody knows what it is called. This sheet records everything a supplier needs in order to find it for you.TSP-ME-01 · 3 pp
GY6 belt size chart and measuring sheetHow to read the three numbers printed on a scooter drive belt, how to measure a belt that has no readable markings left, and a record sheet for the one you have.TSP-ME-02 · 3 pp
Variator roller size chart and measuring sheetDiameter, width and weight are three separate things, and a roller set is only interchangeable on all three. A record sheet with true-size circles and a weighing block.TSP-ME-03 · 3 pp
Scooter brake pad measurement and tracing cardChinese scooter pads are sold by shape, not by model. Trace yours, measure four dimensions, and compare against the listing photograph before you buy.TSP-ME-04 · 3 pp
Chinese scooter bolt, thread and spanner cardWhy an 8mm bolt sometimes takes a 12mm spanner and sometimes a 13mm, how to identify a thread without a gauge, and a true-size thread pitch scale.TSP-ME-05 · 2 pp
Scooter tyre size decoder and record sheetEvery field on a scooter tyre sidewall, what it means, and a record block for the sizes currently fitted to your machine.TSP-ME-06 · 3 pp
Wheel bolt pattern measuring templateMeasure a bolt circle without a special tool, including the odd-numbered patterns where measuring across two holes does not work.TSP-ME-07 · 3 pp
Old part vs new part comparison sheetThe five minutes that stop a return. Check the new part against the old one before you fit anything, while it is still returnable.TSP-ME-08 · 3 pp
Wheel bearing size chart and reverse lookupMeasure bore, outside diameter and width, read the bearing number off the table. Works without knowing what the machine is.TSP-ME-09 · 3 pp
How to measure and identify a Chinese scooter carburettorCarburettors are sold by a bore size and a family name that nobody explains. Measure yours and record the fittings before you order one.TSP-ME-10 · 3 pp
How to measure ATV and go-kart chain and sprocketsChain pitch is a real published standard, so this one can be measured exactly. Count, measure and record before you order.TSP-ME-11 · 2 pp
How to measure a scooter throttle or brake cableTwo numbers, not one. The community disagrees about correct lengths, so this sheet teaches the measurement instead of quoting a figure.TSP-ME-12 · 2 pp
Brake pad measuring board — read all four dimensions at oncePush the pad into the corner and read all four dimensions off the page. Built because look-alike pads differ by millimetres and no photograph shows it.TSP-ME-13 · 3 pp
Brake shoe arc template — which drum size do you have?True-size arcs at the two drum diameters the owner community reports. Lay the shoe on the page and see which one it belongs to.TSP-ME-14 · 3 pp
Oil seal size reverse lookup for scooters and ATVsSeals are described by three numbers and nothing else. Measure them and buy from a bearing factor rather than a scooter shop.TSP-ME-15 · 2 pp
How to measure a scooter or ATV air filterFilters are sold by shape and dimension, never by model. Four measurements and a fitting type settle it.TSP-ME-16 · 2 pp
Measuring exhaust stud spacing and port sizeStud spacing and port bore decide whether an exhaust bolts on. Measure both against a true-size grid before ordering.TSP-ME-17 · 3 pp
How to measure a scooter intake manifoldThe rubber part between the carburettor and the head, and the four dimensions that decide whether a replacement will do the job.TSP-ME-18 · 2 pp
How to measure a spark plug's thread, reach and seatThread diameter, reach and seat type decide whether a plug is safe to fit. All three are measurable, and none of them is the heat range.TSP-ME-19 · 2 pp
How to measure a scooter clutch and clutch bellThe half of the CVT that gets blamed on the belt. Four measurements and a wear inspection, with true-size circles for the bell.TSP-ME-20 · 3 pp
How to measure a scooter shock absorber and forksEye to eye, mount type and fork dimensions. Four numbers that let you order suspension without a model number.TSP-ME-21 · 3 pp
Scooter mirror thread size and the reverse-thread trapTwo common sizes, and one trap that catches everybody. A five-second test settles which you have.TSP-ME-22 · 2 pp
