Free workshop printables
Flagship packs — several sheets, one print job
The sheets that belong together, assembled into a single PDF for a job that takes a whole day.
A pack is not extra content — every sheet inside one is on the site individually and free. It is for the moment when you are about to spend a Saturday on a machine, or drive across a county to look at one, and you would rather press print once than seven times. Packs are assembled from the individual sheets at build time, so a pack can never drift out of date with the sheets it contains.
The Used Scooter Inspection PackEverything for buying a used Chinese scooter, from the first phone call to the first week of ownership. Five sheets, one print job.TSP-PK-01 · 15 pp
The GY6 Workshop PackIdentification, transmission measurement, service records and the two diagnostic chains that cover most no-start faults. Seven sheets.TSP-PK-02 · 21 pp
The Part Measurement PackEverything for identifying and measuring a part you cannot name, and checking the replacement before you fit it. Six sheets with true-size scales throughout.TSP-PK-03 · 17 pp
The Electrical Fault-Finding PackBattery, charging, starter, fuses and wiring, in the order that finds the fault cheapest first. Four sheets and a meter.TSP-PK-04 · 12 pp
The CVT Overhaul PackDiagnose it, measure everything that comes out, and record what goes back in. Four sheets for the system that wears fastest.TSP-PK-05 · 13 pp
The Brake Service PackMeasure the pads, identify the shoes, find out why it drags, and keep the record. Four sheets with true-size instruments throughout.TSP-PK-06 · 13 pp
The Complete Owner's Workshop PackFifteen sheets covering the whole arc of owning one of these machines — identify it, measure it, record it, diagnose it, buy for it. One print job.TSP-PK-07 · 44 pp
