Wheel bolt pattern measuring template
Measure a bolt circle without a special tool, including the odd-numbered patterns where measuring across two holes does not work.
Layout preview of page one. The PDF itself is typeset text, not an image.
Download — free, no email
3 pages. No account, no sign-up, no newsletter. Print it, copy it, hand it to somebody else.
Version v1.0 · September 2026. Opens in your browser's PDF viewer, where you can print directly.
The problem it solves
Bolt patterns with an odd number of studs cannot be measured across two opposite holes, because there is no hole opposite. Three and five stud patterns are common on small ATVs and go-karts, and the usual method silently gives the wrong answer.
Who it is for
- Anyone buying wheels or hubs for an ATV, UTV or go-kart
- Owners checking whether a second-hand wheel will bolt on
- Anyone measuring a pattern with no bolt pattern gauge to hand
What is on it
- A true-size concentric ring template
- The method for even-numbered patterns
- The method for odd-numbered patterns, which is different
- A stud and hole record block
How to use it
- 01Check the calibration rule with a steel rule. On this sheet more than any other, a scaled print gives a wrong answer that looks right.
- 02Lay the wheel face down on the template and line the centre bore up with the centre mark.
- 03Read where the stud holes fall.
