Mystery part measurement sheet
You are holding a part. Nobody knows what it is called. This sheet records everything a supplier needs in order to find it for you.
Layout preview of page one. The PDF itself is typeset text, not an image.
Download — free, no email
3 pages. No account, no sign-up, no newsletter. Print it, copy it, hand it to somebody else.
Version v1.0 · September 2026. Opens in your browser's PDF viewer, where you can print directly.
The problem it solves
The hardest parts to buy are the ones you cannot name. Searching for “that round thing behind the CVT cover” gets nowhere, and sellers cannot help without dimensions. What actually works is a traced outline and eight numbers — and those are the same eight numbers every time, whatever the part is.
Who it is for
- Anyone holding a part they cannot name
- People buying used parts from a seller who has not measured them either
- Anyone comparing a part against a listing photograph with no dimensions
What is on it
- A printed millimetre scale so a scaled printout is caught immediately
- A 5mm tracing grid large enough for most scooter parts
- The eight measurements that identify almost any part
- Fastener, connector and marking record blocks
- Guidance on measuring inside and outside diameters without a caliper
How to use it
- 01Check the calibration bar with a steel rule before you measure anything.
- 02Lay the part flat on the grid and draw round it. Mark every hole centre.
- 03Record the markings exactly, including characters that look like noise — cast numbers are often the real part number.
