GY6 wiring colour and continuity notes sheet
There is no universal wiring colour standard on these machines. This sheet records the one your machine actually uses.
Layout preview of page one. The PDF itself is typeset text, not an image.
Download — free, no email
3 pages. No account, no sign-up, no newsletter. Print it, copy it, hand it to somebody else.
Version v1.0 · September 2026. Opens in your browser's PDF viewer, where you can print directly.
The problem it solves
Wiring colour charts for these machines circulate widely and contradict each other, because there is no standard being followed. Trusting a chart from another machine is how a regulator gets wired to a stator lead. The only reliable record is the one you make with a meter on the machine in front of you.
Who it is for
- Anyone tracing an electrical fault with a multimeter
- Owners rewiring after a previous owner's repairs
- Anyone fitting an aftermarket part whose loom does not match
What is on it
- A wire-by-wire record: colour, from, to, continuity, voltage
- A connector map with space to draw the pin faces
- A note on why colours cannot be trusted between machines
- Basic meter technique for continuity and voltage
How to use it
- 01Disconnect the battery before probing anything you are not deliberately measuring live.
- 02Work one circuit at a time and finish it before starting another.
- 03Record the colour AND the connector position. Colours repeat; positions do not.
